Hammer Crusher

Hammer Crusher

Reference Price:

Get Latest Price Reference Price
  • Production Capacity
    5-150 m³/h

  • Input Size
    ≤350mm

  • Output Size
    ≤20mm

Production capacity 12-1000 t/h

Max Input Size 35-300mm

Discharging Range 3-60mm

Processing Material: gypsum,coal, barite, limestone, coke, rock, slag, brick, stone, ore, glass, etc.

Email:sales@zdzg.com (contact us by one of the three ways)

Email: sales@zdzg.com (contact us by one of the three ways)

Trade Assurance:

Zhongde Heavy Industries Co., Ltd. China(Mainland)

Introduction of Hammer Crusher

1.Hammer crusher is widely used for medium crushing and fine crushing of the soft minerals and the minerals with the medium hardness such as gypsum,coal,limestone,slag,brick,glass,etc in mining,quarry,construction,chemical and other fields.

2.It adopts new technology so that it is wear resistant and impact resistant.

3.The hammer head is made of high quality material,which guarantees the long service life and reduces the down time.

4.It is usually used in small and medium scal production site.

Features of Hammer Crusher

1.Production capacity is 5-150(m³/h),full models for choice.

2.Adjustable discharging size.

3.Compact structure,reliable performance.

4.Wear-resistant,long service life.

5.Easy operation and maintenance,low costs.

Technical Data

  • Hammer Crusher
  • PCZ Heavy Hammer Crusher
Specification Capacity(t/h) Power (kw)
PCΦ400×300 3-10 4P 11
PCΦ600×400 6-22 4P 22
PCΦ800×600 10-40 4P 55
PCΦ1000×800 15-50 4P 75
PCΦ1000×1000 18-55 4P 90

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Rotor diameter×length (mm) Feed Opening Length×width(mm) Feeding Size (mm) Processing Capacity(t/h) Power (kw) Dimensions L×W×H (mm)
PCZ1308 Φ1330×790 870×780 ≤380 60-160 132 2880×2130×2390
PCZ1410 Φ1400×1000 1060×740 ≤450 80-210 2×90(160) 2830×2100×2485
PCZ1610 Φ1600×1000 1090×930 ≤480 100-230 2×132 3370×2415×2750
PCZ1612 Φ1600×1200 1340×1140 ≤500 120-350 2×160 3370×2613×2750
PCZ1615 Φ1600×1500 1570×1140 ≤550 200-550 2×200 3370×2925×2750
PCZ1716 Φ1700×1600 1420×1200 ≤600 400-850 2×250 3520×3000×3210
PCZ1720 Φ1700×2000 2030×1200 ≤650 500-1000 2×400 3670×3390×3330
PCZ1920 Φ1900×2000 1980×1210 ≤750 800-1500 2×500 4490×3910×3600
PCZ2225 Φ2200×2500 2530×1610 ≤1000 1500-3000 1250 4890×5010×4560

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
