Sand Maker

Sand Maker

Reference Price:

Get Latest Price Reference Price
  • Production Capacity
    12-725t/h

  • Max Feeding Size
    25-50mm

  • Environmental Friendly

Production capacity 12-1000 t/h

Max Input Size 35-300mm

Discharging Range 3-60mm

Processing Material: rock, aggregate, gravel, granite, limestone, quartz, basalt, cobbble, dolomite, calcite, etc.

Email:sales@zdzg.com (contact us by one of the three ways)

Email: sales@zdzg.com (contact us by one of the three ways)

Trade Assurance:

Zhongde Heavy Industries Co., Ltd. China(Mainland)

Introduction of Sand Maker

Sand maker, also known as sand making machine, is the key equipment for artificial sand making to provide high quality aggregate for construction, building, highway, water conservancy, etc.


Sand maker is widely used for crushing of hard and brittle materials, such as rock, quartz, concrete aggregate, etc. It is especially suitable for the sand and aggregate making for construction and road paving.

During the crushing process of sand maker, raw materials hit each other and not hit any metal parts. Based on this, it has long service life.?The commonly seen finished products include artificial sand (mechanism sand),silica sand ,etc.


Advantages of Sand Maker

1.Deep chamber rotating design, higher production capacity

2.Adjustable inlet, controllable product granularity

3.Easy maintenance, lower costs

4.Long service life


Technical Data

Model ZDVSI-7611 ZDVSI-8518 ZDVSI-9526 ZDVSI-1140 ZDVSI-1145 ZDVSI-1150
Capacity
(t/h)
Feed both
at center
and sides
120-180 200-260 300-380 450-520 500-610 520-650
Feed at
center
60-90 100-130 150-190 225-260 245-355 255-365
Max.feeding
size(mm)
SoZD
material
35 40 45 50 50 50
Hard
material
30 35 40 40 45 45
Rotation
speed
(r/min)
1700-1890 1520-1690 1360-1510 1180-1310 1150-1300 1150-1300
Double Motor
power(kw)
4P 110 4P 180 4P 264 4P 400 4P 400 4P 500
Overall dimension
(L×W×H)(mm)
3700×2150×2100 4140×2280×2425 4560×2447×2778 5100×2700×3300 5500×2700×3300 5500×2700×3300
Power supply 380V 50HZ
Lubrication
station
Double
motor
power of
oil pump
2×0.31Kw
Safety
assuance
Double oil pumps assure enough oil supply:automatic
switch off with no oil stream or pressure,water cooling
in summer,motor heating stare-up in winter.
Overall
dimension
(L×W×H)
(mm)
820×520×1270
Power of oil
tank heater
2KW
